Low PDL Fiber PLC Splitter 1x12 SC APC ABS Box Type Single Mode

Low PDL Fiber PLC Splitter 1x12 SC APC ABS Box Type Single Mode
Low PDL Fiber PLC Splitter 1x12 SC APC ABS Box Type Single Mode

Large Image :  Low PDL Fiber PLC Splitter 1x12 SC APC ABS Box Type Single Mode

Product Details:
Place of Origin: GUANGDONG CHINA
Brand Name: SLR
Certification: CE ROHS
Model Number: SL-BOX TYPE- PLC-1x12
Payment & Shipping Terms:
Minimum Order Quantity: 500PCS
Price: Negotiable
Packaging Details: Blister or Bag packing
Delivery Time: 8 days after payment
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 7000pcs/day

Low PDL Fiber PLC Splitter 1x12 SC APC ABS Box Type Single Mode

Description
Type: 1x12 Box Type PLC Splitter Parameter: 1X12
Fiber: Single Mode Fiber Cable Diameter: 2.omm
Cable Length: OEM Connector: SC. APC
High Light:

Low PDL Fiber PLC Splitter

,

Box Type Fiber PLC Splitter

,

1x12 Single Mode Fiber Splitter

1x12 PLC Splitter SC / APC Box Type Fiber Coupler Splitter Box



PLC Splitter is based on planar lightwave circuit technology. SL 1x12 Fiber PLC Splitter can distribute or combine 1 optical signal into 12 outputs fibers.



The high performance 1×N or 2×N, single mode, passive power splitter based on PLC technology. The device uniformly splits the optical signals present at the input ports to multiple output ports. Power splitters can also be used in the reverse direction in order to combine multiple optical signals present at the output ports into the input ports.





Application:



FTTX Systems

PON Networks

CATV Links

Optical Signal Distribution





Feature:



Low Insertion loss

Low PDL

Compact Design

Good channel-to-channel uniformity

Wide Operating Wavelength:

From 1260nm to 1650nm

Wide Operating Temperature:

From -40°C to 85°C

High Reliability and Stability







Parameters   Specification
Operating Wavelength (nm) nm 1260~1650
Channel Number   1X4 1X8 1X16 1X32 1X64
Insertion Loss with Connector (Max) dB 7.5 10.7 13.7 17 20.7
Insertion Loss without Connector (Max) dB 7.2 10.5 13.5 16.5 20.5
Uniformity (Max) dB 0.8 1 1.4 1.7 2.5
PDL dB 0.2 0.2 0.3 0.3 0.3
Return Loss dB
Directivity dB
Packaging Dimension (LXWXH) mm 130*100*25 130*100*25 130*100*50 267*100*50 267*100*102







Enviroment Conditions
Operationg Temperature -40 ~ +85
Operationg Temperature -40 ~ +85
Operating Humidity %RH 93
Storage Humidity %RH 93



Cable Info
Fiber Type G 657A
Pigtail Cable 900 um
Connector SC/APC
2xN Splitter Only Single Chip





Advantages Of Fiber Optic Splitter

1. Adopt high strength stainless steel, pass salt spray test

2. Ferrule core is less than 0.2um

3. Adopt 100% new raw material, ROHS compliance

4. Low Insertion loss

5. Low PDL Compact Design

6. Good channel-to-channel uniformity

7. Wide Operating Wavelength: from 1260nm to 1650nm

8. Wide Operating Temperature: from -40℃ to 85℃
